Home > Products > WIRE ROPE

6X19+FC　　6X19+IWS　　6X19+IWR
NOMINAL DIAMETER (MM)	APPROXIMATE WEIGHT (KG/100M)		(N/MM2) NOMINAL T/S
			1470		1570		1670		1770		1870
			(KN) MIN B/L
	FC	IWS IWR	FC	IWS IWR	FC	IWS IWR	FC	IWS IWR	FC	IWS IWR	FC	IWS IWR
2	1.38	1.52	1.81	1.95	1.93	2.08	20.5	2.22	2.17	2.35	2.30	2.48
3	3.11	3.43	4.06	4.39	4.33	4.69	4.61	4.98	4.89	5.28	5.16	5.58
4	5.54	6.10	7.22	7..80	7.71	8.33	8.20	8.87	8.69	9.40	9.18	9.93
5	8.65	9.52	11.20	12.20	12.00	13.00	12.80	13.80	13.50	14.60	14.30	15.50
6	12.50	13.70	16.20	17.50	17.30	18.70	18.40	19.90	19.50	21.10	20.60	22.30
7	17.00	18.70	22.10	23.90	23.60	25.50	25.10	27.10	26.60	28.70	28.10	34.40
8	22.10	24.40	28.80	31.20	30.80	33.30	32.80	35.40	34.70	37.60	36.70	39.70
10	34.60	38.10	45.10	48.80	48.10	52.10	51.20	55.40	54.30	58.70	57.40	62.00
12	49.80	54.90	64.90	70.20	69.40	75.00	73.80	79.80	78.20	84.60	82.60	89.4
14	67.80	74.70	88.40	95.60	94.40	102.0	100.0	108.0	106.0	115.0	112.0	121.0
16	88.60	97.5	115.0	124.0	123.0	133.0	131.0	141.0	139.0	150.0	146.0	158.0
18	112.0	123.0	146	158	156	168	166	179	176	190	186	201
20	138.0	152.0	180	195	192	208	205	221	217	235	229	248
22	167	184	218	236	233	252	248	268	263	284	277	300
24	199	219	259	281	277	300	295	319	312	338	330	357
26	234	258	305	329	325	352	346	374	367	397	388	419
28	271	299	353	382	377	408	401	434	426	460	450	486
30	311	343	406	439	433	469	461	498	489	528	516	558
32	354	390	462	499	493	533	524	567	556	601	587	635
34	400	440	521	564	557	602	592	640	628	679	663	717
36	448	494	584	632	624	675	664	718	704	761	744	804
38	500	550	651	704	695	752	740	800	784	848	828	896
40	554	610	722	780	771	833	820	887	869	940	918	993
42	610	672	796	860	850	919	904	978	958	1030	1010	1090
44	670	738	873	944	933	1000	992	1070	1050	1130	1110	1200
46	732	806	954	1030	1010	1100	1080	1170	1140	1240	1210	1310
48	797	878	1040	1124	1110.0	1201	1181	1277	1252	1354	1322	1430
50	865	952	1128	1220	1205	1303	1281	1386	1358	1469	1435	1552
52	935.0	1030.0	1220	1320	1303	1409	1386	1499	1469	1589	1552	1678
54	1009.0	1111.0	1316	1423	1405	1520	1495	1616	1584	1713	1674	1810
56	1085	1195.0	1415	1530	1511	1634	1607	1738	1704	1842	1800	1946
58	1164.0	1281.0	1518	1641	1621	1753	1724	1865	1828	1976	1931	2088
60	1245.0	1371.0	1624	1756	1735	1876	1845	1996	1956	2115	2066	2235
