*FORGED STEEL SOCKETS THRU 1 1/2" , CAST ALLOY STEEL 1-5/8" THRU 4"
* SPELTER SOCKET TERMINATIONS HAVE AN EFFICIENCY RATING OF 100% , BASED ON THE CATALOG STRENGTH OF WIRE ROPE. RATINGS ARE BASED ON RECOMMENDED USE WITH 6*7,6*19 OR 6*37, IPS OR XIP,XXIP(EIP),RRL,FC,OR IWRC WIRE ROPE.
OPEN GROOVED SOCKETS MEET THE PERFORMANCE REQUIREMENTS OF FEDERAL SPECIFICATION RR-S-550D,TYPE A, EXCEPT FOR THOSE PROVISIONS REQUIRED OF THE CONTRACTOR.
PART NO. | FOR SIZE(INCH) | WEIGHT | DIMENSIONE(IN) | |||||||||
A | C | D | F | G | H | J | L | M | N | |||
EB720104 | 1/4 | 1.10 | 4.56 | 0.75 | 0.69 | 0.38 | 0.69 | 1.56 | 2.25 | 1.56 | 1.31 | 0.31 |
EB720516 | 5/16-3/8 | 1.30 | 4.84 | 0.81 | 0.81 | 0.50 | 0.81 | 1.69 | 2.25 | 1.75 | 1.50 | 0.44 |
EB720716 | 7/16-1/2 | 2.25 | 5.56 | 1.00 | 1.00 | 0.56 | 0.94 | 1.88 | 2.50 | 2.00 | 1.88 | 0.50 |
EB720916 | 9/16-5/8 | 3.60 | 6.75 | 1.25 | 1.19 | 0.69 | 1.13 | 2.25 | 3.00 | 2.50 | 2.25 | 0.56 |
EB720304 | 3/4 | 5.80 | 7.94 | 1.50 | 1.38 | 0.81 | 1.25 | 2.62 | 3.50 | 3.00 | 2.62 | 0.62 |
EB720708 | 7/8 | 9.65 | 9.25 | 1.75 | 1.63 | 0.94 | 1.50 | 3.25 | 4.00 | 3.50 | 3.13 | 0.80 |
EB721000 | 1 | 15.50 | 10.56 | 2.00 | 2.00 | 1.13 | 1.75 | 3.75 | 4.50 | 4.00 | 3.75 | 0.88 |
EB721108 | 11/8 | 21.50 | 11.81 | 2.25 | 2.25 | 1.25 | 2.00 | 4.12 | 5.00 | 4.62 | 4.12 | 1.00 |
EB721104 | 11/4-13/8 | 31.00 | 13.19 | 2.50 | 2.50 | 1.50 | 2.25 | 4.75 | 5.50 | 5.00 | 4.75 | 1.13 |
EB721102 | 11/2 | 47.25 | 15.12 | 3.00 | 2.75 | 1.63 | 2.75 | 5.25 | 6.00 | 6.00 | 5.38 | 1.19 |
EB721508 | 15/8 | 55.00 | 16.25 | 3.00 | 3.00 | 1.75 | 3.00 | 5.50 | 6.50 | 6.50 | 5.75 | 1.31 |
EB721304 | 13/4-17/8 | 82.00 | 18.25 | 3.50 | 3.50 | 2.00 | 3.13 | 6.38 | 7.50 | 7.00 | 6.50 | 1.56 |
EB722000 | 2-21/8 | 129.00 | 21.50 | 4.00 | 3.75 | 2.25 | 3.75 | 7.38 | 8.50 | 9.00 | 7.00 | 1.81 |
EB722104 | 21/4-23/8 | 167.00 | 23.50 | 4.50 | 4.25 | 2.50 | 4.00 | 8.25 | 9.00 | 10.00 | 7.75 | 2.13 |
EB722102 | 21/2-25/8 | 252.00 | 25.50 | 5.00 | 4.75 | 2.88 | 4.50 | 9.25 | 9.75 | 10.75 | 8.50 | 2.38 |
EB722304 | 23/4-27/8 | 315.00 | 27.25 | 5.25 | 5.00 | 3.12 | 4.88 | 10.50 | 11.00 | 11.00 | 9.00 | 2.88 |
EB723000 | 3-31/8 | 380.00 | 29.00 | 5.75 | 5.25 | 3.38 | 5.25 | 11.12 | 12.00 | 11.25 | 9.50 | 3.00 |
EB723104 | 31/4-33/8 | 434.00 | 30.88 | 6.25 | 5.50 | 3.62 | 5.75 | 11.88 | 13.00 | 11.75 | 10.00 | 3.12 |
EB723102 | 31/2-35/8 | 563.00 | 33.25 | 6.75 | 6.00 | 3.88 | 6.50 | 12.38 | 14.00 | 12.50 | 10.75 | 3.25 |
EB723304 | 33/4-4 | 783.00 | 36.25 | 7.50 | 7.00 | 4.25 | 7.25 | 13.62 | 15.00 | 13.50 | 12.50 | 3.50 |
