EVERBRIGHT ALUMINIUM OVAL SLEEVES ARE EXTRUDED FROM A HIGH QUALITY ALUMINIUM ALLOY, AND HEAT TREATED FOR EXCELLENT COLD FORMING OR SWAGING QUALITIES. RETURN EYE SPLICE USING SAFETY ALUMINIUM SLEEVES WILL ATTAIN 95% OF IMPROVED PLOW WIRE ROPE CATALOG STRENGTH WHEN PROPERLY SWAGED.
CAUTION: RETURN EYE SLINGS USING OVAL ALUMINIUM SLEEVES MUST BE PROPERLY SWAGED TO ATTAIN STRENGTH.
PART NO. | SIZE | A | B | C | D | L | WEIGHT |
EB990104 | 1/4" | 19/64 | 19/32 | 17/32 | 27/32 | 1 | 2.3 |
EB990516 | 5/16" | 3/8 | 3/4 | 21/32 | 1 1/32 | 1 17/84 | 4.3 |
EB990308 | 3/8" | 7/16 | 27/32 | 3/4 | 1 5/32 | 1 3/8 | 5.3 |
EB990716 | 7/16" | 1/2 | 1 | 29/32 | 1 13/32 | 1 23/32 | 11 |
EB990102 | 1/2" | 19/32 | 1 11/64 | 1 1/32 | 1 5/8 | 1 15/16 | 16.5 |
EB990916 | 9/16" | 23/32 | 1 3/8 | 1 7/32 | 1 57/64 | 2 7/32 | 22 |
EB990508 | 5/8" | 3/4 | 1 1/2 | 1 3/8 | 2 3/32 | 2 1/2 | 32 |
EB990304 | 3/4" | 53/64 | 1 11/16 | 1 1/2 | 2 3/8 | 2 7/8 | 52 |
EB990708 | 7/8" | 61/64 | 1 7/8 | 1 11/16 | 2 5/8 | 3 | 67 |
EB991000 | 1" | 1 3/32 | 2 7/32 | 1 31/32 | 3 3/32 | 3 3/4 | 125 |
EB991108 | 1 1/8" | 1 9/32 | 2 9/16 | 2 5/16 | 3 19/32 | 4 9/32 | 172 |
EB991104 | 1 1/4" | 1 13/32 | 2 25/32 | 2 1/2 | 3 7/8 | 4 7/16 | 214 |
EB991102 | 1 1/2" | 1 21/32 | 2 19/34 | 3 1/8 | 4 3/4 | 5 35/64 | 390 |
