PRODUCTS
U.S FEDERAL SPECIFICATION
( FF-T-791B ) HOOK & HOOK
THREAD DIA | WORKING | WEIGHT | DIMENSIONS(IN) | ||||||
A | B | C | D | E | F | G | |||
1/4X4 | 400 | 0.30 | 0.25 | 0.45 | 1.59 | 11.94 | 7.94 | 1.27 | 4.00 |
5/16X41/2 | 700 | 0.47 | 0.31 | 0.50 | 1.94 | 13.81 | 9.31 | 1.50 | 4.50 |
3/8X6 | 1000 | 0.75 | 0.38 | 0.56 | 2.30 | 17.72 | 11.72 | 1.77 | 6.00 |
1/2X6 | 1500 | 1.60 | 0.50 | 0.66 | 2.94 | 19.38 | 13.38 | 2.28 | 6.00 |
1/2X9 | 1500 | 1.83 | 0.50 | 0.66 | 2.94 | 25.38 | 16.38 | 2.28 | 9.00 |
1/2X12 | 1500 | 2.08 | 0.50 | 0.66 | 2.94 | 31.38 | 19.38 | 2.28 | 12.00 |
5/8X6 | 2250 | 2.75 | 0.63 | 0.84 | 3.69 | 21.25 | 15.25 | 2.81 | 6.00 |
5/8X9 | 2250 | 3.13 | 0.63 | 0.84 | 3.69 | 27.25 | 18.25 | 2.81 | 9.00 |
5/8X12 | 2250 | 3.50 | 0.63 | 0.84 | 3.69 | 33.25 | 21.25 | 2.81 | 12.00 |
3/4X6 | 3000 | 3.89 | 0.75 | 0.98 | 4.52 | 23.28 | 17.28 | 3.33 | 6.00 |
3/4X9 | 3000 | 4.61 | 0.75 | 0.98 | 4.52 | 29.28 | 20.28 | 3.33 | 9.00 |
3/4X12 | 3000 | 5.43 | 0.75 | 0.98 | 4.52 | 35.28 | 23.28 | 3.33 | 12.00 |
3/4X18 | 3000 | 7.25 | 0.75 | 0.98 | 4.52 | 47.28 | 29.28 | 3.33 | 18.00 |
7/8X12 | 4000 | 8.10 | 0.88 | 1.13 | 5.19 | 37.00 | 25.00 | 3.78 | 12.00 |
7/8X18 | 4000 | 9.95 | 0.88 | 1.13 | 5.19 | 49.00 | 31.00 | 3.78 | 18.00 |
1X6 | 5000 | 9.33 | 1.00 | 1.25 | 5.84 | 26.69 | 20.69 | 4.25 | 6.00 |
1X12 | 5000 | 11.93 | 1.00 | 1.25 | 5.84 | 38.69 | 26.69 | 4.25 | 12.00 |
1X18 | 5000 | 14.00 | 1.00 | 1.25 | 5.84 | 50.69 | 32.69 | 4.25 | 18.00 |
1X24 | 5000 | 17.25 | 1.00 | 1.25 | 5.84 | 62.69 | 38.69 | 4.25 | 24.00 |
11/4X12 | 6500 | 19.00 | 1.25 | 1.50 | 7.22 | 41.56 | 29.56 | 5.13 | 12.00 |
