ROPE DIA. (IN.) | WEIGHT PER | DIMENSIONS (IN.) | ||||||||
A | B | C | D | E | F | G | H | |||
* 1/4 | 6.50 | 2.19 | 1.63 | 1.50 | 0.88 | 0.44 | 0.28 | 0.06 | 0.23 | |
* 5/16 | 11.80 | 2.50 | 1.88 | 1.81 | 1.06 | 0.55 | 0.34 | 0.08 | 0.28 | |
* 3/8 | 21.60 | 2.88 | 2.13 | 2.13 | 1.13 | 0.66 | 0.41 | 0.11 | 0.34 | |
* 7/16 | 34.70 | 3.25 | 2.38 | 2.38 | 1.25 | 0.74 | 0.47 | 0.13 | 0.38 | |
* 1/2 - 9/16 | 51.00 | 3.63 | 2.75 | 2.75 | 1.50 | 0.92 | 0.53 | 0.14 | 0.41 | |
* 5/8 | 75.70 | 4.25 | 3.25 | 3.13 | 1.75 | 1.03 | 0.66 | 0.16 | 0.50 | |
* 3/4 | 158.10 | 5.00 | 3.75 | 3.81 | 2.00 | 1.30 | 0.78 | 0.22 | 0.66 | |
7/8 | 177.80 | 5.50 | 4.25 | 4.25 | 2.25 | 1.47 | 0.94 | 0.22 | 0.75 | |
1 | 313.90 | 6.13 | 4.50 | 4.94 | 2.50 | 1.75 | 1.06 | 0.25 | 0.88 | |
1-1/8 - 1-1/4 | 400.00 | 7.00 | 5.13 | 5.88 | 2.88 | 1.94 | 1.31 | 0.25 | 1.13 | |
1-1/4 - 1-3/8 | 811.00 | 9.06 | 6.50 | 6.81 | 3.50 | 2.35 | 1.44 | 0.38 | 1.13 | |
1-3/8 - 1-1/2 | 1294.80 | 9.00 | 6.25 | 7.13 | 3.50 | 2.78 | 1.56 | 0.50 | 1.13 | |
1-5/8 | 1700.00 | 11.25 | 8.00 | 8.13 | 4.00 | 3.02 | 1.72 | 0.50 | 1.38 | |
1-3/4 | 1775.00 | 12.19 | 9.00 | 8.50 | 4.50 | 3.06 | 1.84 | 0.50 | 1.31 | |
1-7/8 - 2 | 2775.00 | 15.13 | 12.00 | 10.38 | 6.00 | 3.38 | 2.09 | 0.50 | 1.50 | |
2-1/4 | 3950.00 | 17.13 | 14.00 | 11.88 | 7.00 | 3.87 | 2.38 | 0.63 | 1.63 | |
